EC HEPA Fan Filter Unit FFU for Clean Room

FOB Reference Price:Get Latest Price
$299.00 - $499.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
ECFFU
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 Negotiable
Customization:
Customized logo (Min. Order: 5 Sets)
Customized packaging (Min. Order: 5 Sets)

More

Graphic customization (Min. Order: 5 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
OEM
Warranty:
1 year
After-sales Service Provided:
Field maintenance and repair service, Engineers available to service machinery overseas
Applicable Industries:
Flat panel display,Microelectronics, Semiconductor
Casing Material:
SUS304/SPCC
Filter:
HEPA/ULPA
Filter Thinckness:
69mm
Airflow Velocity:
0.45m/s or customizable
Dimension(Nominal):
1200*600mm, 1200*1200mm
Fan Motor:
EBM
Gasket:
EPDM or customizable
Power Supply:
220V 1PH 50/60Hz
Airflow:
1100CMH/2200CMH
Supply Ability
Supply Ability:
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton and Wooden Crate
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 To be negotiated
Product Overview

Fan Filter Unit (FFU) provides the micro-filtered airstream that controls particulate contamination in a cleanroom or laminar flow clean bench. Our comprehensive line includes models based on High-Efficiency Particulate Air (HEPA) filters, rated 99.99% efficient @ 0.3 µm particles, and Ultra Low Penetration Air (ULPA) filters, rated 99.999% efficient @ 0.12 µm particles. Select the lights and other ceiling grid accessories to complete your system.

This reliable, self-powered Fan Filter Unit provides a uniform flow of microfiltered air to meet cleanliness standards down to Class 10 (ISO 4).


Feature
1. EC FFU with HEPA/ULPA filter
2. Low energy consumption (30~40% lower energy consumption compared with AC type)
3. Low noise level (5 dBA lower noise level compared with AC type)
4. Convenient large scale smart control via eLisa system
5. Easy installation


Application
1. Semiconductor

2. Electronics

3. Food and baverage

4. Flat panel display

5. Biological pharmacy and other applications

Specifications
Model
EC FFU
Dimension LxW(mm)
1175x575
1175x1175
Height(mm)
275+25(Inlet Collar)
320+35(Inlet Collar)
Weight(kg,GL)
35.5
54.6
Casing Material
GL/AL/SUS
Appropriate Temperature(℃)
-25~40
Air Velocity(m/s)
0.45(Customizable)
Filter
HEPA/ULPA
Filter Thickness(mm)
69(srtandard mini pleat HEPA)
Gasket
EPDM(Customizable)
Power Supply
220V 1PH 50/60Hz

Easy to Control

It is easy to achieve large-scale smart control via eLisa system, and every FFU is individually controlled and monitored by the central computer. The eLisa system can also indicate the followings: operator logging, energy consumption analysis, diagnosis error messages and error localization, graphics, etc.

Lower Noise Level

This EC FFU is characterized with high efficiency, low noise, and low maintenance with a long life EC motor which can reduce the noise by 5 dBA compared with AC motor.

Lower Energy Consumption

EC motor is more energy saving than AC motor. This EC FFU has a 30~40% lower energy consumption than AC FFU.

Higher Total Static Pressure

The low-pressure drop of the HEPA/ULPA filter, in combined with the high total static pressure of the fan, provide an external static pressure of 50 to 150 Pa at rated airflow.

Lower Off-gassing Components

All components are low off-gassing to meet stringent requirements of specific industries. And PTFE is characterized for zero dissemination of chemical elements (Boron, phosphorus, sodium, potassium, silicon, etc.)

Easy Installation

This product is designed to be easily set in place on ceiling grids without any hold-down clamping. When the filter is knife-edge, the unit can also be utilized in gel-seal ceiling grid.

EC FFU Control System – eLisa

With the eLisa control system, this EC FFU shows the operating condition of all FFUs directly and operates one by one according to the conditions via the host and PC.

Parameters
Model
EC FFU 1175x1175(Glass Fiber Filter)
Airflow(CMH)
1094
ESP-External Static Pressure(Pa)
0
50
100
Filter Efficiency
H13
H15
H13
H15
H13
H15
Initial Resistance(Pa)
95.0
115.0
95.0
115.0
95.0
115.0
TSP-Total Static Pressure(Pa)
95.0
115.0
145.0
165.0
195.0
215.0
Power Consumption(W)
49.0
60.8
65.0
80.8
89.6
100.2
Current(A)
0.231
0.282
0.301
0.372
0.413
0.470
Noise Level(dBA)
42.4
45.8
46.3
48.3
46.9
49.8
